1. RF IN Connect the coaxial cable from the Arial to this socket.
2. RF LOOP THROUGH Connect to your TV or another video system. (Optional)
3. COAXIAL Optional connection to a digital surround sound system.
4. VIDEO Outputs composite video signal to television.
5. COMPONENT VIDEO OUT Connect to your TV component input terminals.
6. AUDIO L/R These sockets output Analog Audio Left/Right signals.
7. HDMI
High definition audio and video output used to connect to a
HDMI device.
8. MAINS CABLE Connected to the main power supply.
