4. PROGRAMMING OPERATIONS EO1-11154
4.9 Store Name Message Programming
4-23
4.9 Store Name Message Programming
A maximum of 128 characters of Store Name Message (32 characters x 4 lines) to be printed on the receipt is
programmed here. This programming is possible only when the store message specification has been selected
by the program option, however, it is not possible when the logo message has been selected.
Any time outside a sale
Mode Lock: SET
1) Menu Tree
2) Operation Flowchart
Main Menu
Depress [1] or [Enter].
“1 MESSAGES” for various message programming is selected.
Depress [↓] twice then [Enter].
or
Depress [3].
“3 STORE MESSAGE” is selected.
The message already programmed is displayed.
[Enter]
The ECR enters the 1st line message input mode
Input a message in the 1st line.
A maximum of 32 one-byte or 16 two-byte characters are input.
[Enter]
The 1st line message is entered and the programmed data is
printed.
[Enter]
The ECR enters the 2nd line message input mode
Input a message in the 2nd line.
A maximum of 32 one-byte or 16 two-byte characters are input.
[Enter]
The 2nd line message is entered and the programmed data is
printed.
[Enter]
The ECR enters the 3rd line message input mode
Input a message in the 3rd line.
A maximum of 32 one-byte or 16 two-byte characters are input.
[Enter]
The 3rd line message is entered and the programmed data is
printed.
[Enter]
The ECR enters the 4th line message input mode
Input a message in the 4th line.
A maximum of 32 one-byte or 16 two-byte characters are input.
[Enter]
The 4th line message is entered and the programmed data is
printed.
[End]
This programming is ended. A long receipt is issued and the
display returns to Main Menu screen.
OPERATION
CONDITION
*: To program a message in a desired line, move the cursor there with
the [
↓
] key then depress the [Enter] key.
*
To Next Page
