4. PROGRAMMING OPERATIONS EO1-11154
4.12 Department Group Name Programming
4-33
3) Example
To program the following name on Department Group 1:
Group 1
F R E S H
Operation LCD Display Remarks
When the ECR is being outside a sale
and in SET mode, depress the [↓] key.
The cursor is moved on to “2 NAMES”.
Depress the [2] or [Enter] key.
Depress the [↓] key.
The cursor is moved on to “2 DP GROUP
NAME”.
Depress the [2] or [Enter] key.
Depress the [Enter] key.
(Department Group 1 is selected.)
When programming a name of another
department group, move the cursor on to a
desired one with the [↓] or [↑] key, then
depress the [Enter] key.
The [C] key depression clears the
department group name already
programmed.
The department group name already
programmed is displayed.
Input a desired name.
Numbers of programmed characters and of
programmable characters are displayed on
the 7-segment numeric display.
Example of key operation)
[Dbl] [F] [R] [E] [S] [H] [Enter]
The [Enter] key depression results in
that the input name is entered and
displayed.
When the [Enter] key is depressed, the
programmed data is printed.
The [End] key depression allows the
ECR to end this programming.
A long receipt is issued and the display
returns to Main Menu screen.
To Next Page
