Chapter 8 Operating instructions; manual mode
This chapter explains the operation of a complete MOT manual test. See the latest MOT
inspection manual for any recent changes.
In This Chapter
Quick manual test mode Class M1, 4, 5L, 7 26
Manual test mode Class M1, 4, 5L, 7 31
Manual test mode class 3 (tested as Class 4) 32
Manual test mode 4WD selectable 33
Manual mode class 1 & 2 35
There are two ways to execute a test:
1) The quick manual test mode: select vehicle type and start the test.
2) The normal manual test mode: select a vehicle from the test queue and start the test.
Quick manual test mode Class M1, 4, 5L, 7
The quick test mode allows you to execute a complete vehicle test without entering vehicle
and customer details (there is no vehicle selected from the test queue).
On the Start screen select 1 - 8 on the remote control/keyboard to start the quick test mode
and select one of the following vehicle types:
KEY CLASS 2X2 OR
4X4 (SELECTABLE)
SERVICE BRAKE
TYPE
PARKING BRAKE ON REAR
OR FRONT AXLE
1 M1 2x2 Dual line Rear
2 M1 4x4 Dual line Rear
3 4 2x2 Dual line Rear
4 4 4x4 Dual line Rear
5 5L 2x2 Dual line Rear
6 5L 2x2 Dual line Front
7 7 2x2 Dual line Rear
8 7 2x2 Dual line Front
Depends on the configuration of the test lane. When configured as a class 4 brake tester,
KEYS 5 until 8 are disabled.
For combinations not listed under these short keys, go to the customer/vehicle screen and
select the correct vehicle. See “Manual test mode Class M1, 4, 5L, 7” on page 31.
Limits are linked to vehicle types 1 to 8 and will be used to judge PASS or FAIL at the end of
the test.
Note
Always see the car manufacturer’s instructions before testing 4x4 vehicles.
