tecan Columbus Washer - Movement Diagrams

6. Adjust Menu
6.2.3 Movement Diagrams
The following diagrams show how the plate support and manifold are moved for
the various settings
Dispense Position
Instrument Front
Instrument Front
Aspirate Position (1)
Instrument Front
Instrument Front
Position to Edge
Position to Centre
Aspirate Position (2) Flat Bottom Wells Only
Instrument Front
Aspirate Bottom Position
Instrument Front
Instrument Front
Bottom Wash Position
Instrument Front
Instrument Front
Overflow Wash Position
Instrument Front
Instrument Front
May 2003 Instructions for Use for Columbus Washer No. I 109 006 Rev No. 2.2 6-5
