tecan Te-VacS - Power Consumption; Vacuum Conditions; Environmental Conditions

3 - Technical Data
Power Consumption
Tecan Vacuum Separator (Te-VacS™) Operating Manual, 391236, en, V4.0 17 / 54
3.3 Power Consumption
Power consumption 48 W
Voltage 24 VDC
3.4 Vacuum Conditions
Max. effective flow rate 33l/min
Max. pressure difference 700mbar
3.5 Environmental Conditions
Te-VacS is intended for indoor operation and storage only. For detailed information
on operating conditions refer to the Operating Manual of the instrument the
Te-VacS is used with. Refer to section “Reference Documents” [ } 8].
Storage temperature 1–60°C (34–140°F)
Storage humidity 5–80% relative (non condensing) at
30°C (86°F) or below
Transport temperature -20 to 60°C (-4 to 140°F)
Transport humidity 20–80% relative (non condensing)
