Technaxx TX-83 User Manual

29
Horizontal patrol
Vertical patrol
Reversal
Mirror
Contrast
Brightness
Chroma
Saturation
IR LED switched ON /Auto IR LED Switched OFF
Switched OFF Switched ON
Resolution: CBR Resolution: VBR
PT speed setting: Slow, Medium, Fast
Note: button can control work mode of IR LED. IR LED may have auto, forced close
two mode, the IR LED will power on or off according to environment light in auto mode; the
IR LED always power off in forced close mode. Some of the buttons above have no function
with this camera model.
Setting device parameters
Click button to enter setting interface, you can set all parameters of the camera
described in chapter 8.3 to 8.8. Only administrator can login to set these parameters.

Technaxx TX-83 Specifications

General

Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
Form factor	-
Mounting type	Wall
Product color	Black
Protection features	Dust resistant
International Protection (IP) code	IP65
Full HD	No
Total megapixels	1 MP
Maximum resolution	1280 x 720 pixels
Supported video modes	720p
Video formats supported	H.264
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Supported graphics resolutions	1280 x 720 (HD 720)
Tilt angle range	70 - 80 °
Camera shutter speed	1/100000 s
Minimum illumination	1 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP, IP, HTTP, DHCP, DNS, DDNS, SMTP, NTP
Detection distance	10 m
Focus adjustment	1.2
Focal length range	0 - 3.6 mm
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Audio formats supported	G.711
Signal-to-Noise Ratio (SNR)	40 dB
Ethernet LAN (RJ-45) ports	1
DC output current	2 A
DC output voltage	12
Power source type	DC
Power consumption (max)	16 W
Operating temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Width	150 mm
Height	200 mm
Weight	1200 g
