Technicolor CGA4131 - SNMP Provisioning for DMZ

3/6/2018 Proprietary and Confidential - Technicolor 102
Application Tab/ DMZ
Click on Application tab then click on DMZ tab. This page displays DMZ setup information.
Figure 9.5
Here a user can enable the DMZ feature, enter the host address (both IPv4 and IPv6) and
save the configuration.
9.5.1 SNMP provisioning for DMZ
S. No.
MIBs
Description
1
rdkbRgFirewallDmzAddress
For DMZ Host IP address set the
following MIB
2
rdkbRgFirewallApplySettings
For all firewall MIBS set the
rdkbRgFirewallApplySettings to 1 to
take effect.
