Technicolor CGA4131 - SNMP Provisioning for Upnp

3/6/2018 Proprietary and Confidential - Technicolor 104
IP address, announce its name, advertise or convey its capabilities upon request,
and learn about the presence and capabilities of other devices.
The user needs to select the required values and options for the above parameters and
press Save button to save them.
Figure 9.7
9.6.2 SNMP provisioning for UPnP
The UPnP feature is controlled via rdkbRgIpMgmtLanUpnp.
S. No.
MIBs
Description
1
rdkbRgIpMgmtLanUpnp
Enable/Disable the UPnP agent
Since the MIB is a table for different SSID, UPnP configuration is supported on all primary
as well as secondary SSIDs.
