13 Isolation
AP Isolation (Access Point Isolation) allows the user to isolate traffic between CPEs on the
same Wi-Fi SSID. This allows a measure of security to prevent hackers from accessing other
CPEs in a public Wi-Fi environment like Hotspot.
13.1 SNMP provisioning for APIsolation
Isolation for BSSID traffic
Isolation for WLAN-WLAN traffic is controlled via therdkbRgDot11BssApIsolation MIB
object.
S. No.
MIBs
Description
1
rdkbRgDot11BssApIsolation
This MIB is written to non-vol and set to
disable (0) after a factory reset. disable(0) -
No AP Isolation, enable(1) - Enable AP
Isolation feature
This is an interface-specific MIB which must be appended with the appropriate interface
index of the BSSID that is being configured for isolation.
Index
Interface
10001
Primary BSSID
10002
Secondary BSSID #1
10003
Secondary BSSID #2
