Technicolor CGA4131 User Manual

3/6/2018 Proprietary and Confidential - Technicolor 51
Channel Width:
The channel bandwidth can be selected manually for Wireless-N connections. For best
performance in a network using Wireless-N, Wireless-G, and Wireless-B devices, it is
suggested to use the AUTO (20 or 40MHz) channel setting. Wireless-N connections will use
the 40MHz channel if there is no interference, while Wireless-G and Wireless-B will still use
the 20MHz channel. For Wireless-G and Wireless-B networking only, select 20MHz only.
Then only the 20MHz channel will be used. For 5GHz the options include AUTO (20 or 40
or 80MHz) the 80MHz will only be used for AC.
Channel:
If AUTO (20 or 40MHz) is selected for the Radio Band setting, then the appropriate Standard
Channel setting will be automatically selected, depending on the Wide Channel setting. If
only 20MHz is selected as the Radio Band setting, select the appropriate channel from the
list provided to correspond with the network settings. All devices in the wireless network
must broadcast on the same channel to communicate.
MAC Address:
The wireless MAC Address is displayed in this field.
Scan Nearby AP:
The Scan button provides a mechanism for the AP to scan for neighboring APs and provides
various statistics on neighbors.
7.1.1 User provisioning for Radio
Various fields can be configured in the Web UI for provisioning the Radio parameters.
Wireless Interface:
The 2.4GHz and 5GHz wireless interfaces can be enabled or disabled using the options in
Figure 7.1 and Figure 7.2.
Network Name:
The network name can either be set/ displayed under this option. The user can also prevent
the network name from being broadcast by selecting the “Hide” option.
Network Mode:
Network Mode determines which 802.11 wireless protocols will be used by the gateway. The
Network Mode has different options available according to the wireless interface:
3. For 2.4GHz: 802.11b only, 802.11g only, 802.11n only, Mixed (802.11b and
802.11g), Mixed (802.11g and 802.11n), Mixed (802.11b, 802.11g and 802.11n).
4. For 5GHz: 802.11a only, 802.11n only, 802.11ac only, Mixed (802.11a and 802.11n),
Mixed (802.11n and 802.11ac) and Mixed (802.11a, 802.11n and 802.11ac).
Channel Width:
