TechniSat DIGITRADIO 1 Instruction Manual

26
27
EN
FR
IT
NL
NW
DK
PL
CZ
SK
> Do not handle the mains adapter with wet hands, as there is a risk of electric
shock!
> In the event of malfunctions or the presence of smoke or smells, remove the
mains adapter from the socket immediately!
> If the device is not being used for an extended period, e.g. before leaving on a
lengthy trip, unplug it from the mains.
> If the device is not being used for an extended period, take the battery out.
> You can damage your hearing if you set the volume too high, particularly when
using headphones.
5 Description of the DIGITRADIO 1
5.1 Scope of delivery
Please check that the scope of delivery is complete before set-up.
1 x DIGITRADIO 1
1 x Battery
1 x Mains adapter
1 x USB cable
1 x Instruction manual
5.2 Special features of the DIGITRADIO 1
The DIGITRADIO 1 is a DAB+/FM receiver with the following functions:
- You can store up to 20 DAB+ and 20 FM stations.
- The radio can receive the following frequencies: FM 87.5-108 MHz (analogue)
and DAB 174.9-239.2 MHz (digital).
- The device has a time and date display.
- Direct selection button.
- Rechargeable battery.
BDA DigitRadio 1.indd 26-27 16/04/2018 16:41

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
