TechniSat DIGITRADIO 1 Instruction Manual

60
61
EN
FR
IT
NL
NW
DK
PL
CZ
SK
12 Technical data / Manufacturer’s notes
Subject to technical changes and errors.
Reception modes DAB/DAB+, FM
Power supply AC input: 100-240V, 50/60Hz / DC output: 5V, 1A
Battery
3.7V/1050mAh Li-Ion, charging current max. 500mA
Battery lifetime up to 10 hours
(speaker at medium volume).
Frequencies
FM: 87.5-108MHz
DAB/DAB+: 174-240MHz
Display OLED
Power consumption
when operating max. 6W (with mains adapter and
battery charging)
when operating typically: 1W (50% volume, no
battery charging)
Standby: < 0.4W
Power off: < 0.3W
Battery-operated power off: < 0.3mW
Audio output performance 1W RMS
Weight 272g
Dimensions (W x H x D) 15.6cm x 9.2cm x 3.34cm
13 Notes
BDA DigitRadio 1.indd 60-61 16/04/2018 16:41

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
