TechniSat DIGITRADIO 1 Instruction Manual

58
59
EN
FR
IT
NL
NW
DK
PL
CZ
SK
Clean the housing with a soft cloth dampened with water. Do not use spirits,
thinners etc.; you could damage the surface of the device.
Only clean the display with a soft cotton cloth. If necessary, use a cotton cloth
with a small amount of non-alkaline, thinned soap solution, based on water or
alcohol.
Rub the cotton cloth gently over the surface.
11 Eliminating malfunctions
If the device is not functioning as intended, run a check using the following table.
If the malfunction cannot be eliminated even after carrying the checks described,
please contact the Technical Hotline.
Symptom Possible cause/remedy
Device cannot be switched on.
The device is not receiving power. Connect the
mains adapter properly to the socket and the
device. Charge the battery.
There is no sound. Increase the volume.
The display cannot be switched on.
Disconnect the device from the mains/remove the
battery and resupply the device with power.
Poor reception via DAB+/FM.
Extend the aerial fully. Change the position of the
aerial or of the DIGITRADIO 1.
Device cannot be operated.
Disconnect the device from the mains/remove the
battery and resupply the device with power.
BDA DigitRadio 1.indd 58-59 16/04/2018 16:41

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
