TechniSat DIGITRADIO 1 Instruction Manual

52
53
EN
FR
IT
NL
NW
DK
PL
CZ
SK
> Use the t or u and OK buttons to select the following options:
[All Sources] (updates via DAB+ and FM)
[Update via DAB] (updates via DAB+ only)
[Update via FM] (updates via FM only)
[No Updates] (Date/time must be entered manually, see Section 9.1.1.)
9.1.3 Setting the time format
In the Set 12/24 Hrs submenu, you can enable the 12 or 24 hour format.
> Press the MENU button and use the t or u buttons to select the [Time] entry.
> Press the OK button.
> Use the t or u buttons to select the [Set 12/24 Hrs] entry and press OK.
> Use the t or u buttons to select one of the following options:
[Set 24 Hrs]
[Set 12 Hrs]
> Press the OK button to accept the setting.
9.1.4 Setting the date format
In the Set Date Format submenu, you can specify the date display format.
> Press the MENU button and use the t or u buttons to select the [Time]
submenu.
> Press the OK button.
> Use the t or u buttons to select the [Set Date Format] entry, then press OK.
> Use the t or u buttons to select one of the following options:
[DD-MM-YYYY] (day, month, year)
[MM-DD-YYYY] (month, day, year)
> Press the OK button to accept the setting.
BDA DigitRadio 1.indd 52-53 16/04/2018 16:41

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
