TechniSat S1 User Manual

Index . . . . . . . . . . . . . . . . . . . . . . .79
4
LNC
input
Input terrestrial
antenna
LNC out-
put
SCART socket
TV
Audio outputs
digital
SCART socket
VCR
Audio outputs
analogue
RS 232
interface
HF
output
Power socket
Inserting the CI module:
> Please note the manufacturer’s instructions for both the CI
module and card.
> Insert the appropriate smart card into the corresponding CI
module.
> Now insert the CI module carefully in the slot provided.
S-Video
output
Video
output
Ein/StandbyEin/Standby
LED display
Programme select
up/down
Slot for CI moduleEject button for CI
module
On/Standby
Alpha-numeric
display
