perform the automatic focussing function. This provides a fine
adjustment of the antenna to achieve optimum reception.
> Press the yellow function key Actions to open a
window displaying the actions available.
> Now use the up/down arrow keys to mark the line
Autofocus.
> Confirm by pressing OK.
> Press the green key (Autofocus) to start the auto-
focus procedure.
While the automatic adjustment is in progress, the
message Autofocus will be displayed. (Fig. 9-13)
9.3.3 Saving a satellite position
NWhen the Autofocus function has been completed, you can
proceed to save the satellite position in memory.
> Use the arrow keys to mark the field Save.
> Press OK.
Now the test transponder selected will check whether
a signal is being received at this position. At the same
time, the system will check whether the position to be
saved is one that is already included in the pre-pro-
gramming. (Fig. 9-14)
If this is the case, the message will be displayed:
Orbital position xx found. Save satellite ?
(Fig. 9-15)
> To save the satellite position in memory, use the
left/right arrow keys to mark the field Yes, and
confirm by pressing OK.
If the check carried out by the test transponder does
not recognise a position as being included in the pre-
programming, or if the signal is too weak, an appro-
priate message will be displayed on screen. (Figs. 9-
16 and 9-17)
> To save the satellite position in memory, use the
left/right arrow keys to mark the field Yes, and
confirm by pressing OK.
9.4 Current satellite list
The satellite positions that have been saved in memory can
be found in the satellite list. Positions that have not yet been
saved are indicated in the list by an “*”.
> To turn the antenna dish to a position in the satellite
list, use the arrow keys to mark the field Current
satellite list.
> Confirm by pressing OK.
> Use the up/down arrow keys to select the desired
position.
> Confirm by pressing OK.
The dish will now be turned to the selected position.
61
(Fig. 8-25)
