Digitize => Laser => Run Scan - Opens the laser digitization dialog
box to set up laser scanning parameters.
Digitize => Laser => Reprocess Data - Opens a data le from a
previous laser scan used to re-generate a 3D object with different
ltering options to improve the quality of the 3D object.
Exit - Closes WinCNC.
Conguration Menu
D/A Calibration - Calibration Settings for D/A (Digital to Analog)
spindle speed control. This can only be used if D/A has been acti-
vated in the WinCNC Program.
Settings Menu
Positions - Opens the positions dialog box with options to view and
edit stored positions. (Ex: G53 P# to call position in G-Code)
Home Positions - Opens the positions dialog box with options to
view and edit stored home positions. (Ex: G0 H# to call home pos.)
Tool Positions - Opens the tool positions dialog box with options to
view and edit stored tool positions for use with automatic tool chang-
ers. (This requires an additional software feature to be enabled)
Tool Library - Edits and views the dened tool library.
Local Coordinates - View XYZ coordinates.
View Menu
Resolution - View current resolution settings for each axis.
Acceleration - View current acceleration settings for each axis.
Limits - View current limit settings for each axis.
Inputs - Views real-time input states.
Outputs - Views real-time output states.
