Titan Series WinCNC Manual
WinCNC
WinCNC Controller
WinCNC Users Guide Page 13
Toolbars - Enable/Disable the main toolbar.
Toolbars=> Size - Change toolbar from small to large.
Refresh View (F5) - Refreshes the screen.
Clear Screen (CTRL+C) - Clears the message display window.
Options Menu
Soft Limits (CTRL+L) - Enable/Disable the software limits.
Keyboard (CTRL+K) - Enable/Disable the keyboard transit/jog con-
trol used to move the machine with the keyboard.
Buttons - Used to customize user buttons.
Auto Repeat - Auto populate the command line with the last com-
mand executed.
Auto Run - Enable/Disable the auto run feature.
Auto Preview - Enable/Disable the auto preview feature.
Single Step (CTRL+P) - Enable/Disable single line execution of G-
Code les.
Units Menu
Inches - Sets the unit of measure to inches.
Centimeters - Sets the unit of measure to centimeters.
Millimeters - Sets the unit of measure to millimeters.
Transit Menu
Slow (F2) - Sets the transit speed to slow.
Medium (F3) - Sets the transit speed to medium.
Fast (F4) - Sets the transit speed to fast.
Program Operation
