{ } Braces
Used to substitute axis or parameter values in a line of G-Code.
Internally dened variables as well as constant numbers can be
used within the braces. Following is a list of internally dened
variables and what they represent.
Internally Dened Variables
TP1 Tool number, tool changer 1.
TP2 Tool number, tool changer 2.
TN1 Tool number 1 + 10.
TN2 Tool number 2 + 20.
TS1 Tool number 1 + tool changer 1 offset.
TS2 Tool number 2 + tool changer 2 offset.
TH1 Tool height for tool changer 1.
TH2 Tool height for tool changer 2.
TM1 Height of a tool length measure switch. Set using M37.1.
TM2 Height of a second tool length measure switch.
TMX X position of a tool length measure switch.
TMI X position of a second tool length measure switch. (In
rare cases, all heads cannot reach the same tool measure
switch.)
TMY Y position of a tool length measure switch.
TMJ Y position of a second tool length measure switch.
TMD Rapid move distance for auto tool measure.
TMF Feed rate for auto tool measure.
LZ0 Current G92 value for axis 0.
LZ1 Current G92 value for axis 1.
LZ2 Current G92 value for axis 2.
LZ3 Current G92 value for axis 3.
LZ4 Current G92 value for axis 4.
LZ5 Current G92 value for axis 5.
