WinCNC Users Guide Page 83
Internally Dened Variables continued
THM 1 if THC Manual Voltage Mode is enabled, 0 if disabled.
THA 1 if THC Auto Voltage Mode is enabled, 0 if disabled.
THO The specied output channel used to turn the torch on/off
for THC.
THI The specied input channel used to monitor the “arc good”
signal for THC.
THP 1 if pierce height for THC is enabled, 0 if disabled.
THC 1 if cut height for THC is enabled, 0 if disabled.
THZ The specied pierce height for THC.
THR The specied cut height for THC.
THS The specied pierce delay for THC.
THE The specied end delay for THC.
THD The specied switch compensation amount.
THL The specied torch lift amount.
THF The feed rate specied for THC.
Additional variables can be dened in the CNC.MAC le. Dened
variables and constants can be used together with simple math
operators. ( * ) multiplication, ( / ) division, ( + ) addition, ( - ) subtrac-
tion.
Example: G0Z{TH1+2} moves Z to tool height 1, plus 2 units.
NOTE: ANY use of braces requires a value or axis spec and a num-
ber. The second parameter inside the braces must be a number.
