WinCNC Users Guide Page 88
G81 Drill Cycle - G81 X# Y# Z# R# F#
Moves to XY specied at Rapid velocity. Moves to R (clearing
height) at Rapid velocity. Moves to Z specied at Feed velocity.
Moves back to R at Rapid velocity. F allows you to set the feed
rate.
G82 Dwell Cycle - G82 X# Y# Z# R# P# F#
Moves to XY specied at Rapid velocity. Moves to R (clearing
height) specied at Rapid velocity. Moves to Z specied at Feed
velocity. If P is specied, bit pauses that amount of time at the
bottom of the hole, then moves back to R at Rapid velocity. P is
measured in milliseconds (thousandths of one second). F allows
you to set the feed rate.
G83 Peck Drill Cycle - G83 X# Y# Z# R# Q# F#
Moves to the XY specied at Rapid velocity. On the rst peck,
moves to R retract height at Rapid velocity, moves to peck depth Q
at Feed velocity, then moves back to retract height at Rapid veloc-
ity. On each subsequent peck, moves at Rapid velocity to within
0.05” of previous peck depth, then moves at Feed velocity to next
peck depth. Cycle repeats until Z depth is reached. Then moves
back at Rapid velocity to retract height R. The F allows user to set
the feed rate.
