L8 Turns Backlash Compensation On, Restore INI values
for all axes.
Examples:
L8XY - Turn Backlash Compensation On, Restore INI values
for specied axes.
L8X.001 - Turns Backlash Compensation On, Set new value
for specied axis.
L9 Turns Backlash Compensation Off.
L10 Cut Array - L10 R# C# X# Y# E#
Sets up array cutting. Repeats all code following until the end of
the le or another L10 is reached. Program pointer is moved back
to initial L10. The head is moved to the next column or row speci-
ed by XY at rapid velocity. Cycle repeats until all array points
have been cut. L10 specied without RCXY values can be used
to end an array cut. Lines that follow will not be repeated. If an ‘E’
is found on the L10 command line then WinCNC will skip the nal
move back to the starting position at the end of the array. If no ‘E’
is found then WinCNC will move back to the starting position at the
end of the array.
**A G92XY is required after the L10 Line for the cut array to work.
X# is the units to move the x axis before starting the next cut.
Y# is the units to move the x axis before starting the next cut.
R# is the number of rows.
C# is the number of columns.
Example: L10 r5 c5 x4 y4 e1 or L10 r1 c4 x6 y0
G92xy G92xy
G90 G90
G01 x3 m98 Texas.tap
G01 y3
G01 x0 **End with L10 if using more
G01 y0 than one L10 array.
