Titan Series WinCNC Manual
WinCNC
WinCNC Controller
WinCNC Users Guide Page 95
L29 Clear Home Flags - L29 XYZ
Clears all require home ags. Axes can be used with the com-
mand to clear require home ags only on the specied axes.
L29.1 Ignore Home Flags
Ignores require home ags for all axes during execution of the cur-
rently running le.
L30 Knife Mode On
Enables support for the Knife Mode.
L30.1 Knife Parameters L30.1 A# Z# P#
Set Lift Angle, Lift Position, and Plunge depth for knife. When
amount of change in the angle of the knife exceeds A# the knife
will lift to make the turn. A# is also used for angle correction in Tar-
get Mode: see Knifemode=. Z# is the position to lift to. P# is the
position that the knife will plunge to.
L31 Knife Mode Off
Disables support for the Knife Mode.
L32 Saw Mode On
Enables support for the Saw Mode.
L33 Saw Mode Off
Disables support for the Saw Mode.
L34 AutoAuxOut Enable - L34 D#
Enables an auxiliary output that will turn on during G1/G2/G3
moves, and will turn off for all other moves. L34 D# sets the dwell
time in seconds used when the channel is set to on and L35 D#
sets the dwell time in seconds when the channel is set to off.
When the ‘D’ parameter is used with the L34 command the “Au-
toAuxOut” mode does not change. L34 parameters are set in the
WINCNC.INI le by the “autoaux=” line.
