WinCNC Users Guide Page 104
L802 Scan Given Rectangle - L802 X# Y# I#
Scans a given rectangle XY with an increment of I in and up/down,
and side-to-side style scan. (Use automatic scan)
L803 Scan Given Rectangle - L803 X# Y# I#
Scans a given rectangle XY with an increment of I in an up/down
style scan.
L810 Scan Slice (Drop-off Detection) - L810 FILENAME.
EXT X# Y# I# K#
Digitizes a slice (line), either in X direction, or Y direction and
saves the points to a text le. If a drop-off is encountered, or dis-
tance stated in X or Y is reached, the slice is saved and the scan is
ended. Only one axis can be scanned at a time: X or Y. Uses
up/down, and side-to-side probe type.
FILENAME.EXT - replace with your lename. Do not surround
with quotation marks.
X# - is the actual X axis distance that you want the probe to travel
looking for an edge. If it nds one, the le is saved and the scan
ends.
Y# - works like X#, except on the Y axis.
I# - is the maximum increment for the horizontal axis.
K# - is the vertical increment (how high the probe raises).
L820 Disable axisadj
Disables automatic axis position adjustment.
L821 Enable axisadj
Enables automatic axis position adjustment.
L901 Limit Switch Debounce - L901 D#
Changes the limit switch debounce. D# can be 1-30.
L910 Disable G-Code Line Display
Disabling G-Code display when running large G-Code les can re-
duce CPU and memory usage resulting in better overall computer
system performance.
