Technogym Plurima MF30 - Dismantling and Replacing the Handles Top Cable; Dismantling and Replacing the Bottom Handles Cables

5.4
dIsmAntlIng And replAcIng the hAndles top cAble
Operation description: Action:
Dismantling and replacing
the handles top cable
“7. Cables” to page 37
ONCE THE GUARDS HAVE BEEN REMOVED:
1. Free the crimped cable by pulling it from its end (D2) (using a 4
mm Allen wrench.)
2. Loose the pulleys and remove the cable.
5.5
dIsmAntlIng And replAcIng the bottom hAndles cAbles
Operation description: Action:
Dismantling and replacing
the boom handles cables
“7. Cables” to page 37
ONCE THE GUARDS HAVE BEEN REMOVED:
 Raisetherstplatetoslackenthetensiononthecable.
1. Free the cable by pulling it from one of the rubber handles’ end
(D1).
2. Free the crimped cable from its housing (using a
17 mm and a 19 mm spanners as well as a 4 mm Allen wrench).
3. Loosen the screws of the pulley cable (using a 6 mm Allen
wrench and a 17 mm spanner).
4. Remove the cable and replace it.
PLURIMA - the smart multistation:
Technical Service Guide - Vers. 2.1
Page 27
