Operation description: Action:
Dismantling adjustable
seat
1. Remove the sliding bearings (using a 4 mm Allen wrench.)
2. Unscrew the side screws that support the pin and the spring
(using 4 mm Allen wrench); then remove the seat.
3. Unscrew the screws of the spring guard (using a
Phillips screwdriver) and remove the guard.
PLURIMA - the smart multistation:
Technical Service Guide - Vers. 2.1
Page 33
