Operation description: Action:
Dismantling roller pads
adjustment system
1. Move the rollers to position 5.
2. Through the hole in the frame, unscrew the screw that anchors
the moving assembly (using a 5 mm Allen wrench.)
3. By pulling the knob, slide out and remove the moving assem-
bly.
PLURIMA - the smart multistation:
Technical Service Guide - Vers. 2.1
Page 32
