Technogym Skillmill - 7.13 DISASSEMBLING THE ROLLER UNIT BEARINGS

If the bearing bracket must be disassembled, remove the two upper screws on the rear beam.
10. Remove the screws that x the roller unit to the equipment, as detailed in the video
“Disassembly instructions - Skillmill” available on the e-learning platform.
11. Remove the roller unit.
To ret the roller unit, follow the disassembly instructions in reverse order.
7.13 DISASSEMBLING THE ROLLER UNIT BEARINGS
1. Remove 4 slats as explained in paragraph “7.9.1 Disassembling the slats”.
2. Remove the bearing from the roller unit.
Skillmill:
Technical Service Guide - Rev. 3.5
