2. Depending on the type of equipment:
• - On Skillmill Connect (DJK03): check if the magnets are present:
- if not present, install the magnets.
- if present, check the magnets.
The distance between the RPM sensor and the closest magnet (completing a full rotation of the
pulleyusingafeelergauge)shouldbeD=0.8mm(D=0.0315”).
• - On Skillmill Console (DJK04): make sure the magnets are not present:
- if present, remove them and replace them with standard screws.
- if not present, check the screws.
The distance between the RPM sensor and the closest screw (standard) (completing a full rotation
ofthepulleyusingafeelergauge)shouldbeD=0.8mm(D=0.0315”).
 - NowchecktheLowKitlabel:ifnotpresent,orifthebatchnumberis074210,replace
the Low Kit.
Make sure the spare Low Kit doesnotindicatethedefectivelot074210onthelabel.


in detail in the following paragraph.
6.6.11.1 PROCEDURE FOR DETECTING THE MINIMUM SPEED ON SKILLMILL
Adjust the braking in order to move the belt smoothly around a speed of approx. 3.0 km/h
(1.86 miles/h).
Graduallyslowdownto2.0km/h(1.2miles/h),tryingtodecreasethespeedeverytwoorthree
seconds, using the criterion of observing a stable value on the LCD for at least two or three seconds.
You can only be sure that the Low Kit is able to correctly detect the speed X if the value X is shown
onthedisplay,withauidandnon-oscillatingmovement,foratleast3seconds.
If a certain value is seen on the LCD only for an instant but not in a stable manner, even though an
exercise is being performed at a constant speed, this means the value is below the minimum speed
that can be detected by the Low Kit. Increase the belt speed slightly until a stable value is seen on
the LCD. This stable value represents the minimum speed detected by Skillmill.
If the detected stable value is not 2.1 km/h (1.3 miles/h), readjust the distance of the sensor/replace
the sensor.
