Information on the display indicates the following:
$ Line 1. The succeeding number of the last weld performed and the total number of welds of which
this sequence is composed.
$ Line 2. The number of the step with which the last weld was performed and the total number of
steps.
$ Line 3. The program number and the RMS current value of the last weld.
$ Line 4. The progressive number of the next weld.
WELD 008 OF 013
STEP 03 OF 04
PROG. 03 RMS 10.45
NEXT WELD 009
