The TE500 weld control unit permits to perform welds with different welding current supply and check
methods. The table below shows the different modes, the operations required for activating them and
the compatible functions.
FIX PW% IK
Self-calibration procedure
x
z z
Rogowski ring sensor
x x
z
Stepper function NO YES YES
Program sequence function YES YES YES
CUR control mode YES YES YES
DEG control mode YES YES YES
Current compensation YES YES NO
Welding analysis YES YES YES
Proportional valve YES YES YES
Rogowski ratio All
Only the one with
which the Self-
calibration is
performed
Only the one with
which the Self-
calibration is performed
Automatic mains
compensation
NO NO YES
First insertion delay
z z z
Ammeter capacity All
Only the one
recommended in Self-
calibration
Only the one
recommended in Self-
calibration
WORK MODES
x = not compulsory
z = compulsory
