Tecnar Rotoweld 3.0 - Figure 23 Add Welder; Figure 24 New Welder Name

This document contains information considered proprietary and confidential to Tecnar Automation Ltd
40101-00020-00– Rev 1.2
Revision date: 2017-07-31
Page 30 of 48
!
In this popup menu, you can move the cursor with the joystick to the desired
welder’s name. Once the desired welder’s name is selected, press the
SELECTION/ENTER button to confirm your choice. If you decided to return
to the welding screen without choosing a new welder’s name, only press the
STOP button to escape and return to the welding screen.
To add a new welder’s name, move the cursor to ADD WELDER (figure 23).
!
FIGURE 23 ADD WELDER
Then press the SELECTION/ENTER button. You will then be prompted to fill
the new desired welder’s name (figure 24).
!
FIGURE 24 NEW WELDER NAME
