6.11 ROOT PROCESS EDITING
The ROOT PROCESS screen (figure 31) is used to adjust several important
welding parameters.
You can select, delete or edit ROOT PROCESS.
!
FIGURE 31 ROOT PROCESS
With the joystick, move the cursor to the ROOT PROCESS section (figure
32).
!
FIGURE 32 ROOT PROCESS SECTION
Press the SELECTION/ENTER button. A popup window will be displayed
(figure 33).
!
FIGURE 33 ROOT PROCESS PARAMETERS
