6.13 BURNBACK SETTINGS
6.13.1 DURATION:
Move the joystick on the DURATION parameters (figure 34).
FIGURE 36 DURATION PARAMETERS
By pressing the SELECTION/ENTER knob you will be able to change the
desired value by moving the joystick up or down (figure 35).
!
FIGURE 37 EXIT DURATION PARAMETERS
Once finished, you can exit the DURATION parameters by pressing the
SELECTION/ENTER knob.
POWER SETTING:
Move the joystick on the POWER SETTING parameters (figure 38).
!
FIGURE 38 POWER SETTING PARAMETERS
By pressing the SELECTION/ENTER knob you will be able to change the
desired value by moving the joystick up or down (figure 39).
!
FIGURE 39 POWER SETTING
Once finished, you can exit the POWER SETTING parameters by pressing
the SELECTION/ENTER knob.
