6.20 MISCELLANEOUS
6.20.1 TRAVEL SPEED MIN & MAX:
Move the joystick on the TRAVEL SPEED parameters (figure 53).
!
FIGURE 67 MISCELLANEOUS-TRAVEL SPEDD MIN & MAX
By pressing the SELECTION/ENTER knob you will be able to change the
desired value by moving the joystick up or down (figure 54).
!
FIGURE 68 TRAVAEL SPEES MIN $ MAX
Once finished, you can exit the TRAVEL SPEED parameters by pressing the
SELECTION/ENTER knob.
! !
