6.17 FILL PARAMETERS
6.17.1 GMAW: OR SAW:
Choosing between GMAW or SAW option.
6.17.2 TORCH ANGLE:
Move the joystick on the TORCH ANGLE parameters (figure 58).
!
FIGURE 53 TORCH ANGLE PARAMETERS
By pressing the SELECTION/ENTER knob you will be able to change the
desired value by moving the joystick up or down (figure 59).
!
FIGURE 54 TORCH ANGLE
Once finished, you can exit the TORCH ANGLE parameters by pressing the
SELECTION/ENTER knob.
6.18 BURNBACK SETTINGS
6.18.1 DURATION:
Move the joystick on the DURATION parameters (figure 60).
FIGURE 55 DURATION
By pressing the SELECTION/ENTER knob you will be able to change the
desired value by moving the joystick up or down (figure 61).
FIGURE 56 DURATION
Once finished, you can exit the DURATION parameters by pressing the
SELECTION/ENTER knob.
