10.5 Replacement of printer
(1) Turn off the power and pull out the power plug.
(2) Remove the upper cover of the apparatus
(3) Pull out all the plugs in the interior of upper cover that are connected with the
CPU board and power board, etc.
(4) Remove the printer board, and printer installation board
(5) Pull out the two cables of the printer which is connected with the printer board, and remove the
four bolts fixing the printer and then the printer can be removed.
(6) After the new printer is replaced, install the apparatus in reverse procedure of the above.
The plugs shall be connected according to their labels; otherwise the
a
aratus will not be able to work.
