TECO JSDAP Series Simplified Manual

11
400V
dn-08 Display
Drive Model
JSDAP
Motor Model
Motor Standards
Encoder
Specification
Cn030 Setting Watt(KW) Speed(rpm)
H1211
25B
JSMA-PMB10BB
1.0 2000
2500
H1212 JSMA-PMB10BH 8192
H1215 JSMA-PMB10B5 15 bit(ABS)
H1217 JSMA-PMB10B7 17 bit
H121A JSMA-PMB10BA 17 bit(ABS)
H1231 JSMA-PMB15BB
1.5 2000
2500
H1232 JSMA-PMB15BH 8192
H1235 JSMA-PMB15B5 15 bit(ABS)
H1237 JSMA-PMB15B7 17 bit
H123A JSMA-PMB15BA 17 bit(ABS)
H1251 JSMA-PMB20BB
2.0 2000
2500
H1252 JSMA-PMB20BH 8192
H1255 JSMA-PMB20B5 15 bit(ABS)
H1257 JSMA-PMB20B7 17 bit
H125A JSMA-PMB20BA 17 bit(ABS)
H1311
35B
JSMA-PMB20BB
2.0 2000
2500
H1312 JSMA-PMB20BH 8192
H1315 JSMA-PMB20B5 15 bit(ABS)
H1317 JSMA-PMB20B7 17 bit
H131A JSMA-PMB20BA 17 bit(ABS)
H1331 JSMA-PMB30BB
3.0 2000
2500
H1332 JSMA-PMB30BH 8192
H1335 JSMA-PMB30B5 15 bit(ABS)
H1337 JSMA-PMB30B7 17 bit
H133A JSMA-PMB30BA 17 bit(ABS)

TECO JSDAP Series Specifications

General

Brand	TECO
Model	JSDAP Series
Category	Servo Drives
Language	English
