TECO JSDAP Series Simplified Manual

12
dn-08 Display
Drive Model
JSDAP
Motor Model
Motor Standards
Encoder
Specification
Cn030 Setting Watt(KW) Speed(rpm)
H1341
35B
JSMA-PMH30BB
3.0 1500
2500
H1342 JSMA-PMH30BH 8192
H1345 JSMA-PMH30B5 15 bit(ABS)
H1347 JSMA-PMH30B7 17 bit
H134A JSMA-PMH30BA 17 bit(ABS)
H1401
50B
JSMA-PMB30BB
3.0 2000
2500
H1402 JSMA-PMB30BH 8192
H1405 JSMA-PMB30B5 15 bit(ABS)
H1407 JSMA-PMB30B7 17 bit
H140A JSMA-PMB30BA 17 bit(ABS)
H1411 JSMA-PMH30BB
3.0 1500
2500
H1412 JSMA-PMH30BH 8192
H1415 JSMA-PMH30B5 15 bit(ABS)
H1417 JSMA-PMH30B7 17 bit
H141A JSMA-PMH30BA 17 bit(ABS)
H1421 JSMA-PMH44BB
4.4 1500
2500
H1422 JSMA-PMH44BH 8192
H1425 JSMA-PMH44B5 15 bit(ABS)
H1427 JSMA-PMH44B7 17 bit
H142A JSMA-PMH44BA 17 bit(ABS)
H1501
75B
JSMA-PMH44BB
4.4 1500
2500
H1502 JSMA-PMH44BH 8192
H1505 JSMA-PMH44B5 15 bit(ABS)
H1507 JSMA-PMH44B7 17 bit
