TECO JSDAP Series Simplified Manual

57
★
Cn037.3
Communication RS232 is read and written to the
selection of EEPROM.
0 X
0
│
1
ALL 544H 0025H
Setting Explanation
0 JSDAP Command address (E8~EC)
1
JSDAP Command address (70~74)
* While setting to 1, Pn407~Pn410 are
prohibited from applying.
★
Cn038
Communication protocol
0 X
0
│
8
ALL 545H 0026H
Setting Explanation
0 7 , N , 2 ( Modbus , ASCII )
1 7 , E , 1 ( Modbus , ASCII )
2 7 , O , 1 ( Modbus , ASCII )
3 8 , N , 2 ( Modbus , ASCII )
4 8 , E , 1 ( Modbus , ASCII )
5 8 , O , 1 ( Modbus , ASCII )
6 8 , N , 2 ( Modbus , RTU )
7 8 , E , 1 ( Modbus , RTU )
8 8 , O , 1 ( Modbus , RTU )
★
Cn039
Communication time-out dection
0 sec
0
│
20
ALL 567H 0027H
Setting non-zero value to enable this function,
communication Time should be in the setting period
otherwise alarm message of communication
time-out will show. Setting a zero value to disable
this function.
★
Cn040
Communication response delay time
0
0.5
msec
0
│
255
ALL 5EDH 0028H
Delay Servo response time to master control unit.
Cn041
Absolute encoder rotation value reset
0 X
0
│
1
ALL 524H 0029H
Setting Explanation
0 Disable
1 Reset absolute encoder rotation value
Cn041.1
Absolute encoder battery Alarm Reset(AL-16)
0 X 0 ~ 1 ALL 524H 0029H
Setting Explanation
0 Disable
1 Clear AL-16 after reset power
Cn043
Analog monitor output ratio (MON1)
100 %
1
│
1000
ALL C72H 002BH
For example,the Analog monitor output ratio is
10V/1.5 times speed when we set 100%, if we want
10V/0.75 times speed, please set 200%
Cn044
Analog monitor output ratio (MON2)
100 %
1
│
1000
ALL C73H 002CH
Please refer to Cn043.
Cn045
~
Cn047
Reserved -- -- -- -- -- --
Cn048
Automatic gain 1&2 switch delay time
0
x02
msec
0
│
10000
Pi
Pe
S
C7AH 0030H
Set the delay time from speed loop 1 to speed loop
2, when two control speed loops are used.
Cn049
Automatic gain 1&2 switch time
0
x02
msec
0
│
10000
Pi
Pe
S
C7BH 0031H
Set the switch time from speed loop 1 to speed loop
2, when two control speed loops are used.
Cn050
Automatic gain 1&2 switch time
0
x02
msec
0
│
10000
Pi
Pe
S
C7CH 0032H
Set the switch time from speed loop 2 to speed loop
1, when two control speed loops are used.
