TECO JSDAP Series Simplified Manual

58
Parameter Name & Function Default Unit
Setting
Range
Control
Mode
Communication
Address
RS232 RS485
Cn051
Low voltage protection level
190 Volt
170
│
190
ALL 5F0H 0033H
Set the delay time of Cn052, which triggers low
voltage protection alarm, when voltage of drive
input power is lower than Cn051.
Cn052
Low voltage protection alarm delay time
0
x250
msec
0
│
100
ALL C8BH 0034H
Set the delay time of Cn052, which triggers low
voltage protection alarm, when voltage of drive
input power is lower than Cn051.
Cn053
Current offset automatic adjust (only used in
servo off)
0 x
0
│
1
ALL B91H 0035H
Setting Explanation
1
Drive executes current offset adjust and
then clears setting to 0 automatically when
the adjustment is finished.
Cn054
Drive warning setting
0000 x
0000
│
FFFF
ALL C8DH 0036H
Parameter Cn054 set by hex code, and each bit
represents for each alarm. Setting the
corresponding bit to 1 for the alarm is an warn mode.
Drive warns and then trigger alarm after
continuously executing the setting time of Cn055
when alarm occurs.
Ex: Set Cn054 to 0801H, and then set Cn055 to 100
when low voltage or overspeed alarm is a warn,
which triggers alarm one second later.
0000100000000001 is the setting status, presenting
in binary.
Cn055
Drive warning delays the time of triggering
alarm
0
x10
msec
0
│
300
ALL C8EH 0037H
Parameter Cn054 set by hex code, and each bit
represents for each alarm. Setting the
corresponding bit to 1 for the alarm is an warn mode.
Drive warns and then trigger alarm after
continuously executing the setting time of Cn055
when alarm occurs.
Ex: Set Cn054 to 0801H, and then set Cn055 to 100
when low voltage or overspeed alarm is a warn,
which triggers alarm one second later.
0000100000000001 is the setting status, presenting
in binary.
