TECO JSDAP Series Simplified Manual

81
Multi-Function Input Parameters
Parameter Name & Function Default Unit
Setting
Range
Control
Mode
Communication
Address
RS232 RS485
★
Hn601.0
Hn601.1
DI-1 Function
Changed
by mode
X
01
│
20
︵
HEX.
︶
ALL C23H 0501H
Setting Explanation
Signal Functions
00
NON
Unused
01
SON
Servo On
02
ALRS
Alarm Reset
03
PCNT
PI/P Switching
04
CCWL
CCW Limit
05
CWL
CW Limit
06
TLMT
External Torque Limit
07
CLR
Clear Pulse Error Value
08
LOK
Servo Lock
09
EMC
Emergency Stop
0A
SPD1
Speed 1
0B
SPD2
Speed 2
0C
MDC
Control Mode Switch
0D
INH
Position Command Inhibit
0E
SPDINV
Speed Inverse
0F
G-SEL
Gain Select
10
GN1
Electronic Gear Ratio Numerator 1
11
GN2
Electronic Gear Ratio Numerator 2
12
PTRG
Position Trigger
13
PHOLD
Position Hold
14
SHOME
Start Home
15
ORG
Home Position Reference (Origin)
16
POS1
Internal Position select 1
17
POS2
Internal Position select 2
18
POS3
Internal Position select 3
19
POS4
Internal Position select 4
1A
TRQINV
Torque Inverse
1B
RS1
Torque CW Selecting
1C
RS2
Torque CCW Selecting
1D
MDC2
Control mode selection for tool
turret
1E
POS5
Internal position command
selection 5
(Tool NO. selection 5)
1F
POS6
Tool NO. selection 6
20
VDI
Virtual digital input
★New setting will become effective after re-cycling the
power.
Warning! If any of programmable Inputs of DI-1 ~ DI-12 are
set for the same type of function
then the logic state selection ( NO or NC selection) for these
inputs must be the same type.
Otherwise an Alarm will be displayed. AL-07 (Abnormal DI/DO
programming).
P. S.：DI_Jog function only work in Position mode (Cn01 = 2、6、
A)
DI_Jog_1 DI_Jog_2 Function
0 0 No JOG
1 0
JOG
Excitation Forward
0 1
JOG
Excitation Reverse
1 1
JOG
Excitation zero-run
★
New setting will become effective after re-cycling the power.
