82
Parameter
Name & Function Default Unit
Setting
Range
Control
Mode
Communication
Address
RS232 RS485
★
Hn601.2
DI-1 Active Level
0 X
0
│
1
ALL C23H 0501H
Setting Explanation
0 Low Active (short with IG24)
1 High Active
★
Hn602
DI-2
Changed
by mode
X 000~ 120
ALL C24H 0502H
Please refer to Hn601
★
Hn603
DI-3
X 000~ 120
ALL C25H 0503H
Please refer to Hn601
★
Hn604
DI-4
X 000~ 120
ALL C26H 0504H
Please refer to Hn601
★
Hn605
DI-5
X 000~ 120
ALL C27H 0505H
Please refer to Hn601
★
Hn606
DI-6
X 000~ 120
ALL C28H 0506H
Please refer to Hn601
★
Hn607
DI-7
X 000~ 120
ALL C29H 0507H
Please refer to Hn601
★
Hn608
DI-8
X 000~ 120
ALL C2AH 0508H
Please refer to Hn601
★
Hn609
DI-9
X 000~ 120
ALL C2BH 0509H
Please refer to Hn601
★
Hn610
DI-10
X 000~ 120
ALL C2CH 050AH
Please refer to Hn601
★
Hn611
DI-11
X 000~ 120
ALL C2DH 050BH
Please refer to Hn601
★
Hn612
DI-12
X 000~ 120
ALL C2EH 050CH
Please refer to Hn601
★
New setting will become effective after re-cycling the power.
Warning! If any of programmable Inputs of DI-1 ~ DI-12 are set for the same type of function then the logic state
selection (NO or NC selection) for these inputs must be the same type. Otherwise an Alarm will be displayed. AL-07
(Abnormal DI/DO programming).
