Quick Set-up Parameters
Parameter
Name & Function Default Unit
Setting
Range
Control
Mode
Chapter
Speed Loop Gain 1. ( Same function as Sn211)
◆qn401
Speed loop gain has a direct effect on the frequency
response bandwidth of the Speed-control loop.
Without causing vibration or noise Speed-loop-gain
can be increased to obtain a faster speed response.
If Cn025 (load Inertia ratio) is correctly set, the
speed-loop-bandwidth will equal to speed-loop-gain.
40 Hz
10
│
450
Pi
Pe
S
5-3-8
5-5
Speed-loop Integral time 1. (Same function as
Sn212)
◆qn402
Speed loop integral element can eliminate the steady
speed error
and react to even slight speed variations.
Decreasing Integral time can improve system rigidity.
The formula below shows the relationship between
Integral time and Speed loop Gain.
ainSpeedLoopG
tTimeConsntegrationSpeedLoopI
×
×≥
π
2
1
5tan
100
x0.2
ms
1
│
500
Pi
Pe
S
5-3-8
5-5
Speed Loop Gain 2. (Same function as Sn213)
◆qn403
Refer to qn401
40 Hz
10
│
450
Pi
Pe
S
5-3-8
5-5
Speed Loop Integration Time Constant 2.
(Same function as Sn214)
◆qn404
Refer to qn402
100
x0.2
ms
1
│
500
Pi
Pe
S
5-3-8
5-5
Position Loop Gain 1. (Same function as Pn310)
◆qn405
Without causing vibration or noise on the mechanical
system the position loop gain value can be
increased to speed up response and shorten the
positioning time.
Generally, the position loop bandwidth should not be
higher then speed loop bandwidth. The relationship
is according to the formula below:
5
2
ainSpeedLoopG
opGainPositionLo ×≤
π
40 1/s
1
│
450
Pi
Pe
5-4-6
5-5
Position Loop Gain 2 (Same function as Pn311)
◆qn406
Please refer to qn405
40 1/s
1
│
450
Pi
Pe
5-4-6
5-5
Position Loop Feed Forward Gain
◆qn407
It can be used to reduce the follow up error of
position control and speed up the response.
If the feed forward gain is too large, it might cause
speed
Overshoot and in position oscillations which result in
the repeated ON/OFF operation of the output
contact
INP(“In Position” output signal).
0 %
0
│
100
Pi
Pe
5-4-6
5-5
