N3 Drive Operations Manual
A (Advanced) Parameter Summary; A131 – A147 43
Parameter
No.
LCD Display
Description
Range/Code
Factory
Setting
Remarks
A131
Motor rated Slip
Motor Slip
Compensation (%)
0.0 – 100.0
0.0
1 & 6
A132
Max frequency
Maximum
Frequency (Hz)
0.20 - 400.00
50.00/
60.00
4 & 6
A133
Max Voltage
Maximum
Frequency
Voltage
Ratio (%)
0.0 - 100.0 (l 100% based on AC
Input Volt A007)
100.0
6
A134
Mid frequency
Mid Frequency
(Hz)
0.10 - 400.00
25.00/
30.00
4 & 6
A135
Mid Voltage
Mid Frequency
Voltage Ratio (%)
0.0 - 100.0 (100% based on AC
Input Volt A007)
50.0
6
A136
Min frequency
Minimum
Frequency (Hz)
0.10 - 400.00
0.50/ 0.60
6
A137
Min Voltage
Minimum
Frequency
Voltage Ratio (%)
0.0 - 100.0 (100% based on AC
Input Volt A007)
1.0
6
A138
A139
(Reserved)
Reserved
A140
PID Mode Sel
Mode Selection
0000: Disabled
0001: Bias D Control
0002: Feedback D Control
0003: Bias D Reversed
Characteristics Control
0004: Feedback D Reversed
Characteristics Control
0005: Frequency Command + Bias
D Control
0006: Frequency Command +
Feedback D Control
0007: Frequency Command + Bias
D Reversed Characteristics
Control
0008: Frequency Command +
Feedback D Reversed
Characteristics Control
0000
A141
Feedback Gain
Feedback Gain
0.00 - 10.00
1.00
1
A142
PID Gain
Proportional Gain
0.0 - 10.0
1.0
1
A143
PID I Time
Integration Time
(Seconds)
0.0 - 100.0
10.0
1
A144
PID D Time
Differentiation
Time
(Seconds)
0.00 - 10.00
0.00
1
A145
PID Offset
PID Offset
0000: Positive
0001: Negative
0000
1
A146
PID Offset Adj
PID Offset Adjust
(%)
0 - 109
0
1
A147
Output Filter T
Output Lag Filter
Time (Seconds)
0.0 - 2.5
0.0
1
