Appendix E- EMC Dimensions, FS Type Filter E1
Appendix E – EMC Filter Dimensions
Filter Dimensions
The following Fig.’s AE.1– AE.3 show the dimensions of the filter models covered in Section 16.0. The electrical
connections and specifications will be covered by the cut sheet received with the specific filter.
W
L1 L2 L3
D
H
A
B
(4) Mounting
Holes
Ia
Ib
FS
Fig. AE.1 FS Type Filter
SIZE
FILTER
MODEL
Inverter Mounting
Dimensions
in (mm)
External Filter Dimensions
in (mm)
Ia
Ib
W
H
D
B
A
FS 6146 - 11 - 07
FS 6147 - 8.9 - 07
FS 6149- 4.6 - 07
3.07
(78)
5.91
(150)
3.58
(91)
7.56
(192)
1.10
(28)
2.91
(74)
7.13
(181)
FS 6146 - 27 – 07
FS 6147 - 19 – 07
FS 6149 - 10 07
4.51
(114.6)
6.71
(170.5)
5.04
(128)
46
(215)
1.46
(37)
4.37
(111)
8.03
(204)
FS 6147 - 39 – 07
FS 6149 - 28 - 07
6.81
(173)
9.61
(244)
7.40
(188)
11.34
(289)
1.65
(42)
6.50
(165)
10.94
(278)
Cont.
