TECO S310+ Series User Manual

App2
Register No.
Content
2522/A022H
Bit Description 1 0
Sequence
input
status
0 Terminal S1
On OFF
1 Terminal S2
On OFF
2 Terminal S3
On OFF
3 Terminal S4
On OFF
4 Terminal S5
On OFF
5
reserved
6
Multi-function
Output1 (RELAY1)
On OFF
7
reserved
8
reserved
9
reserved
Contact
output
A
reserved
B
reserved
C
reserved
D
reserved
E
reserved
F
reserved
2523/A023H frequency command (100/1Hz)
2524/A024H Output frequency (100/1Hz)
2525/A025H Output voltage command (10/1V)
2526/A026H DC voltage command (10/1V)
2527/A027H Output current (10/1A)
2528/A028H
reserved
2529/A029H
reserved
252A/A02AH
reserved
252B/A02BH
reserved
252C/A02CH TM2 AIN input value (1024 / 10V) *1
252D/A02DH Keypad AIN input value (1024 / 10V) *1
252E/A02EH reserved
252F/A02FH reserved
2530/A030H reserved
(Note) 1、Do not write in data for the reserved register.
5.Function Code
5.1Read the data in the holding register [03H]
Master unit reads the contents of the holding register with the continuous number for the specified
quantity.
Note：1、Limit number of read data，RTU: 37，ASCII:17.
2、Can only Continuous read the address of the same Group
