TECO S310+ Series User Manual

3-9
3.4.2 General Specifications
Item
S310+ series
Control Mode V/F or SLV
Frequency Control
Range
0.01~400.00 Hz
Starting torque
140% /1Hz (SLV mode)
Speed control range
1:50 (SLV mode)
Speed control accuracy ±1% (SLV mode)
Setting resolution Digital: 0.01Hz, Analog: 0.06Hz/ 60Hz(10bits)
Keypad setting Set directly with▲▼ keys or the VR on the keypad
Display Function
Five digital LED and status indicator: display frequency
/
Inverter parameter/ Fault Log/ Program Version
External signal setting
1. External potentiometer0-10V/ 0-20mA
2. Provides up/down controls, speed control or automatic
procedure control with multifunctional contacts on the
terminal block(TM2)
Frequency Limit
Function
Upper/lower frequency limits
Gen eral Control
Carrier frequency 1 ~ 12 kHz
V/F pattern 6 fixed patterns, 1programable curve
Acc/Dec control Acc/Dec time (0.1 ~ 3,600 seconds)
Multifunction analog
output
5 functions (refer to description on 2-12)
Multifunction input 12 functions (refer to description on 01-00~01-04)
Multifunction output 6 functions (refer to description on 01-09)
Other Functions
Momentary Power Loss Restart, Overload Detection, 8 preset
speeds，2/3-wire Control, torque boost, Slip Compensation,
Frequency Upper/ Lower Limit, Modbus slave and PC/PDA Link,
Auto Restart.
Communication Control
1. Control by RS485
2. One to one or one to many (RS485 ONLY) control.
3. BAUD RATE/STOP BIT/PARITY/bit can be set
Braking Torque
About 20﹪, standard model the specified external braking
resistors can provide 100%
Operation temperature
-10℃ ~ +50℃(Power distribution panel: -10℃ ~ +40℃)
Storage temperature
-20 ~ 60℃
Humidity
0 – 95% Relative Humidity(Non-condense)
Vibration
1G (9.8m/s2 )
Enclosure
IP20
