4.1.5 Control Mode Selection
The inverter provides two control modes:
1、 V/F mode 2、 General Vector Control Mode
2、 Users can set the control mode according to their own application.The inverter default Value
is V/F mode. Please set control mode and motor related parameters according to the
following procedure before using(The Vector control mode mode only suitable for the motors
with the same power rating as the inverter, or one size bigger or smaller, only suitable for the
motors with the same power rating as the inverter).
Control mode selection
00-00=0 或 1（VF/ Vector mode）
※ NOTE:
1. The V/F mode is suitable for:
(1) A inverter loads multiple motors at the same time.
(2) The motor nameplate is unknown，Or the motor specification is special causing
Auto-tuning fail。
(3) The inverter and the horsepower of the motor differ more than one level.
2. If a inverter loads multiple motors, only V/F mode can be chosen,and should follow these
principles:
(1) Motor rated current (06-01)will add up all the rated current of the motors。
(2) The others set the appropriate V/F curve parameters (05-04～05-09).
3. When the motor nameplate is unknown，the inverter will be setted to the internal value of
TECO standard motor parameters.
Setting procedure f
or
control
mode
Control mode
V/F control
Control mode selection
00-00=0
Set the following parameters：
Volts/Hz Patterns (V/F) 00-01
No-load current of Motor 05-01
(<=06-01)
Motor rated Slip Compensation 05-02
V/F max voltage 05-03
Maximum Frequency (Hz) 05-04
Maximum Frequency Voltage Ratio 05-05
Medium Frequency2 05-06
Medium Frequency Voltage Ratio2 05-07
Medium Frequency1 05-08
Medium Frequency Voltage Ratio1 05-09
Minimum Frequency 05-10
Minimum Frequency Voltage Ratio 05-11
Torque Compensation Gain 05-16
Torque Compensation Frequency 05-17
Motor Rated Current 06-01(OL1 reference)
Setting the following parameters：
Motor Rated Voltage 06-00
Motor Rated Current 06-01
Motor Rated Power 06-02
Motor Rated Rotation Speed 06-03
Motor Rated Frequency 06-04
NOTE：V/F max voltage 05-03
Should be setted to the Motor
Rated Voltage.
VF/ Vector Control mode
Running Auto tuning(06-05=1)
END
